Using Kubernetes Ingress to navigate traffic to Services

Introduction

In the previous article, I introduced the basic concepts of Kubernetes Ingress, and how to use Ingress along with related components (Nginx Ingress Controller and cert-manager) to automatically issue TLS certificates when deploying HTTPS applications. In this article, I'll show you how to define rules in Ingress to route traffic to different Services based on your needs.

Prepare Docker Image

First, you'll need a Docker image to get started. You can either use two different Docker images or follow my next instructions to prepare a Docker image.

Here's a code block to create a NodeJS server that displays a title based on an environment variable input:

import express from 'express'

const port = 3000
const title = 'This is NodeJS Typescript Application'
const app = express()

app
  .get('/', (_, res) => {
    res.send((process?.env?.TITLE ?? title) + '! Current time is ' + Date.now())
  })
  .listen(port, () => {
    console.log(`Server is running http://localhost:${port}`)
  })

Next, let's build a Docker image and push it to Google Container Registry or Docker Hub. (See here for more details.)

Working with Kubernetes

Next, you'll need to set up the Nginx Ingress Controller and cert-manager.

Just like in the previous tutorial, you need to define a Deployment and a Service. Then, define a rule for Ingress to route traffic to the Service. In this example, I'll define two Deployments and two Services. There will also be two rules for Ingress to route traffic accordingly. The end result will be that accessing the URL /app1 will navigate to Service 1, and accessing /app2 will navigate to Service 2.

The content of the `deployment.yml` file will be as follows:

apiVersion: apps/v1
kind: Deployment
metadata:
  name: deployment-name-1
spec:
  replicas: 1
  selector:
    matchLabels:
      app: label-name-1
  template:
    metadata:
      labels:
        app: label-name-1
    spec:
      restartPolicy: Always
      containers:
        - name: express-ts
          image: express-ts # replace with your image
          ports:
            - containerPort: 3000
              name: deployment-port
          env:
            - name: TITLE
              value: Application 1 # input any words
---
apiVersion: v1
kind: Service
metadata:
  name: service-name-1
spec:
  selector:
    app: label-name-1
  ports:
    - protocol: TCP
      port: 80 # port service
      targetPort: deployment-port # port pod
---
apiVersion: apps/v1
kind: Deployment
metadata:
  name: deployment-name-2
spec:
  replicas: 1
  selector:
    matchLabels:
      app: label-name-2
  template:
    metadata:
      labels:
        app: label-name-2
    spec:
      restartPolicy: Always
      containers:
        - name: express-ts
          image: express-ts # replace with your image
          ports:
            - containerPort: 3000
              name: deployment-port
          env:
            - name: TITLE
              value: Application 2
---
apiVersion: v1
kind: Service
metadata:
  name: service-name-2
spec:
  selector:
    app: label-name-2
  ports:
    - protocol: TCP
      port: 80 # port service
      targetPort: deployment-port # port pod
---
apiVersion: cert-manager.io/v1
kind: Issuer
metadata:
  name: letsencrypt-production
spec:
  acme:
    server: https://acme-v02.api.letsencrypt.org/directory
    email: any-email@gmail.com
    privateKeySecretRef:
      name: letsencrypt-production
    solvers:
      - http01:
          ingress:
            class: nginx
---
apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: ingress-name
  annotations:
    cert-manager.io/cluster-issuer: letsencrypt-production
    nginx.ingress.kubernetes.io/rewrite-target: /$2
    nginx.ingress.kubernetes.io/force-ssl-redirect: "true"
spec:
  ingressClassName: nginx
  tls:
    - hosts:
        - your-domain.com
      secretName: secret-name
  rules:
    - host: your-domain.com
      http:
        paths:
          - path: /app1
            pathType: Prefix
            backend:
              service:
                name: service-name-1
                port:
                  number: 80
          - path: /app2
            pathType: Prefix
            backend:
              service:
                name: service-name-2
                port:
                  number: 80

You can see that the `paths` field has defined two paths: `/app1` to access `service-name-1` and `/app2` to access `service-name-2`.

Next, apply the changes to create the resource:

kubectl apply -f deployment.yml

Note: I've defined all resources in a single file for simplicity, but in practice, you should separate each resource into individual YAML files for better management.

Resources have been created
